Manual Stapling Machine

All the machine parts are cast by HT20-40 material, after machining use the screws to fix the four parts Base, post,arm, crossbeam into one lathe bed.

Product Feature：

All the machine parts are cast by HT20-40 material, after machining use the screws to fix the four parts Base,post,arm, crossbeam into one lathe bed。The series stitching machine is carefully designed,it adopt the advantages of similar products in China and abroad,.It has new appearance, high-speed, stable operation,fixed stitching ability, hard metal base, long life, etc.

Stitching speed: 250 times / min.

Stitching thickness :2-7-layer.

del	Stapling Speed(nail/min)	Thickness of stapling	Length of sretched arm(mm)	Maximum size of the carton(mm)	Weight(kg)	Power (kw)
DXJ-900	250	3/5/7ply	900	90011001100	400	0.75
DXJ-1200	250	3/5/7ply	1200	120011001100	600	0.75
DXJ-1400	250	3/5/7ply	1400	140011001100	800	0.75
DXJ-2000	250	3/5/7ply	2000	200011001100	1200	0.75
Nails	16#,17#,18#
