Automatic High Speed Cardboard Laminator Machine | Full Servo Control

The fully automatic flute laminating machine supplied by OUYE is mainly used to laminate linerboards to the flutes of corrugated board or laminate one cardboard to another cardboard with adhesive. The suitable corrugated flute patterns include A, B, C, E and F flute. This automatic flute laminator is designed with auto suction feeding system for both top linerboards and bottom corrugated boards. It is really an ideal choice for producing high end packaging boxes.
the fast speed, computerized high –speed mount, up to 15000sheets per hour (within 700MM ofpaper)

Our Automatic High Speed Cardboard Laminator Machine is equipped with a full servo computer control system, which ensures high precision, high speed and stable performance during the laminating process. It is specially designed for corrugated cardboard, carton and paper packaging production, greatly improving production efficiency and product quality.
The machine has the advantages of easy operation, low energy consumption, low failure rate and long service life. It can realize automatic paper feeding, laminating and discharging, reducing manual labor and improving work efficiency.

With strict quality control and international certifications, our full servo computer laminator machine is widely recognized by customers worldwide. We provide customized solutions and professional after-sales support to meet different production requirements.

Main technical parameter
Machine model	OY-1450G	OY-1700G
Max paper size	1450*1450mm	1700*1450mm
Min paper size	400*380mm	400*380mm
Surface paper thickness	200-800g/m²	200-800g/m²
Bottom paper thickness	0.5-12mm	0.5-12mm
Machine speed	176m/min	176m/min
Laminating precision	±1mm/m	±1mm/m
Machine size	1400025002400mm (L * W * H)	1400027002400mm (L * W * H)
Machine power	25KW	28KW
Machine weight	7.2T	7.8T
